Type

1KW-24Vdc

1KW-48Vdc

1KW12V

Wind turbine

1KW

1KW

1KW

Solar panel

300Wp

300Wp

300Wp

Battery

24Vdc

48Vdc

12Vdc

Function

Charge, control

Operating environment

Temperature -10-40°C,humidity≤80%

PWM constant pressure voltage

>28Vdc

>56Vdc

>14Vdc

3-phase load voltage of the wind turbine

29±1Vdc

58±1Vdc

15±1Vdc

Recovery charging voltage of the wind turbine

27±1Vdc

54±1Vdc

13.5±1Vdc

Solar stop charge voltage

29±1Vdc

58±1Vdc

15±1Vdc

Solar recovery charging voltage

<28Vdc

<56Vdc

<14Vdc

Low-voltage of the battery

20±1Vdc

40±1Vdc

10±1Vdc

Self-provided connecting wire of the battery

>8mm²

>6mm²

>16 mm²

PWM fuse

63A

25A

100A

Solar fuse

16A

10A

40A

Charging fuse

63A

32A

125A

Size of the controller (mm)

480*360*230

480*360*230

480*360*230

Weight of the controller

12Kg

11Kg

12 Kg

Size of the load (mm)

395*300*125

395*300*125

395*300*125

Weight of the load

5.5 Kg

5 Kg

5.5Kg
