Model Name

Z-600W

Rated power

600w

Rated DC voltage

DC 12V/24V/48V

Rated current

25 A

Rated speed

640r/m

Number of blade

5 pcs

Starting wind speed

2.5 m/s

Cut-in wind speed

3 m/s

Rated wind speed

12 m/s

Engine

Three-phase permanent magnet generator

Rotor diameter

1850mm

Blade material

Carbon fiber

Output line anti-winding device

Overall three-phase commutator

Over-speed wind protection

Tip stall protection + turned protection + Electromagnetic brake

Life span

15 years

Equipment surface protection

Aluminum oxide + plastic coating

N.W

20 Kg
