400W Wind Turbine For Home System

    Details



    Model Name

    Z-400W



    Rated power

    400w





    Rated DC voltage

    DC 12V/24V

    Rated current

    34A/17A

    Rated speed

    740r/m

    Number of blade

    3 pcs

    Starting wind speed

    3 m/s

    Cut-in wind speed

    45 m/s

    Rated wind speed

    12 m/s

    Engine

    Three-phase permanent magnet generator

    Rotor diameter

    1450mm

    Blade material

    Carbon fiber

    Output line anti-winding device

    Overall three-phase commutator

    Over-speed wind protection

    Tip stall protection + turned protection + Electromagnetic brake

    Life span

    15 years

    Equipment surface protection

    Aluminum oxide + plastic coating

    N.W

    18 Kg
