SOLAR PANEL 250W POLY

    Details


    Solar Panel  Characteristics

    Model No.

    SFP250 W

    Maximum Power at STC (Pmax)

    250 W

    Optimum Operating Voltage (Vmp)

    30V

    Open - Circuit Voltage (Voc)

    43.2 V

    Optimum Operating Current (Imp)

    8.33A

    Short - Circuit Current (Isc)

    9.2A

    Cell Efficiency

    about 17.2 %

    Operating Module Temperature

    -40 °C to +85 °C

    Maximum System Voltage

    1000 V DC (IEC) / 600 V DC (UL)

    Diodes

    3 by pass

    Power Tolerance

    -3/+3 %


    STC: irradiance 1000 W/m2, module temperature 25 °C, AM=1.5; Power measurement tolerance: ± 3%
