Solar Panel 150W Mono

    Details


    Solar Panel  Characteristics



    Model No.

    SFP150 W

    Maximum Power at STC (Pmax)

    150 W

    Optimum Operating Voltage (Vmp)

    18 V

    Open - Circuit Voltage (Voc)

    21.6 V

    Optimum Operating Current (Imp)

    8.33A

    Short - Circuit Current (Isc)

    9.16A

    Cell Efficiency

    about 17.2 %

    Operating Module Temperature

    -40 °C to +85 °C

    Maximum System Voltage

    1000 V DC (IEC) / 600 V DC (UL)

    Diodes

    2 by pass

    Power Tolerance

    -3/+3 %


    STC: irradiance 1000 W/m2, module temperature 25 °C, AM=1.5; Power measurement tolerance: ± 3%
