Power

200W

300W

400W

500W

600W

Solar panels

≥200W

≥300W

≥400W

≥500W

≥600W

DC input range

22-60VDC

MPPT Voltage

24-48V

DC MAX current

15A

20A

30A

45A

50A

AC MAX output

230W

330W

430W

550W

650W

AC output range

120VAC(90-140VAC) or 230VAC(190-260VAC)

Frequency range

50Hz/60Hz(Auto control)

Power Factor

>97.5%

THD

<5%

Phase Shift

<2%

Peak Efficiency/110V

>88%

>88%

>86%

>85%

>85%

Stable Efficiency/110V

>86%

>86%

>85%

>84%

>83%

Peak Efficiency/220V

>90%

>90%

>88%

>88%

>85%

Stable Efficiency/220V

>88%

>88%

>86%

>86%

>84%

Protection

Islanding; Short-circuit; converse connection; Low Voltage; Over Voltage; Over temperature Protection

Work Temperature

-25℃-65℃

Work Humidity

0%~90%RH non-condensing

Grade of Waterproof

Indoor design

Show

LED

Cooling

Fan

Stand-by Power

2-3W

EMC Reference

EN61000-6-3:2007 EN61000-6-1:2007

Grid Disturbance Reference

EN 50178+EN 62109-1+VDE0126-1-12

Grid Detection Reference

DIN VDE 1026 UL1741

Certificate

CE

Mounting dimension

16*13CM
