Rated Power

200W

300W

400W

500W

600W

Solar Panels

60 cells solar panel, Vmp is 28-30V, Voc is 35-38V or 72 cells solar panel, Vmp is 35-39V, Voc is 42-46V

DC MAX Input

240W

360W

480W

600W

720W

DC Input Range

20-48VDC

MPPT Voltage

22-40V

DC MAX. Current

10A

15A

20A

25A

35A

AC MAX. Output

230W

330W

430W

550W

650W

AC Output Range

120VAC/230VAC(90-260VAC)

Frequency Range

50Hz/60Hz(Auto control)

Power Factor

>97.5%

THD

<5%

Phase Shift

<2%

Efficiency

120VAC(90-140VAC)

Peak Efficiency

>89%

>89%

>88%

>88%

>87%

Stable Efficiency

>87%

>87%

>86%

>86%

>85%

Efficiency

230VAC(190-260VAC)

Peak Efficiency

>92%

>91%

>90%

>90%

>88%

Stable Efficiency

>90%

>89%

>87%

>87%

>86%

Protection

Islanding; Short-circuit; converse connection; Low Voltage; Over Voltage; Over temperature Protection

Work Temperature

‘-25℃-65℃

Work Humidity

0%~90%RH non-condensing

Grade of Waterproof

Indoor design

Show

Luminous Diode(LED)

Cooling

Fan

Stand-by Power

＜2W

EMC Reference

EN61000-6-3:2007 EN61000-6-1:2007

Grid Disturbance Reference

EN 50178+EN 62109-1+VDE0126-1-12

Grid Detection Reference

DIN VDE 1026 UL1741

Certificate

CE

Mounting Dimension

16*13CM
